    AI890 Digital I O Module IS 8Ch S800 3BSC690071R1 Analog Input

    Ask Lasest Price
    Brand Name : ABB
    Model Number : AI890 3BSC690071R1
    Price : Negotiation
    Payment Terms : T/T PAYONEER
    Supply Ability : 30
    Delivery Time : 3-5 work day
    Certification : Does not supply
    • Product Details
    • Company Profile

    AI890 Digital I O Module IS 8Ch S800 3BSC690071R1 Analog Input

    AI890 3BSC690071R1 Analog Input Module IS 8-Ch S800 I O Module


    Product Information Of : AI890 3BSC690071R1

    BrandABB
    ModelAI890
    ID3BSC690071R1
    SIZE102*119*45mm
    Weight0.3KG

    Medium Description :

    0(4)...20mA single ended. Intrinsic Safety Interface.

    Use Module Termination Unit TU890 or TU891

    Channel Type:

    AI

    Number of Input Channels:

    8

    Number of Output Channels:

    0

    The AI890 Analog Input Module has 8 channels. The module includes Intrinsic Safety protection components on each channel for connection to process equipment in hazardous areas without the need for additional external devices.


    Each channel can be either a current input or power and monitor a two-wire process transmitter. The current input is for externally powered transmitters. The input voltage drop of the current input is typically 3 V, PTC included. The transmitter supply for each channel is able to provide at least 15 V at a 20 mA loop current to power Ex certified process transmitters and is limited to 23 mA in overload conditions. All eight channels are isolated from the ModuleBus and power supply in one group. Power to the input stages is converted from the 24 V on the power supply connections.


    TU890 and TU891 Compact MTU can be used with this module and it enables two wire connection to the process devices without additional terminals. TU890 for Ex applications and TU 891 for non Ex applications.
