OMRON S8VK-X48024A-EIP 100 to 240 VAC Power rating 480 W 24 VDC -
40 C to + 70 C
Product information OMRON S8VK-X48024A-EIP :
- Manufacturer : Omron
- Product No. :S8VK-X48024A-EIP
- Product replacement time, output voltage, output current, and more
are acquired on the network and can be managed all at once
- Product status can be checked on-site using the indication monitor
- Operation possible at ambient temperatures from -40 to 70°C
- Power Boost function at 150% (240 and 480 W)
- Side-by-side mounting possible (up to 55°C)
- UL Class 2 conformance (90 W or less)
- Complies with EN/IEC 61558-2-16
- Coated PCBs for better resistance to environment
- 12 month Northern Industrial Warranty
More information:
• EMI (radiated emissions) conform to Class B when this Power
Supply is installed in a control panel.
• EN/IEC 61558-2-16 The S8VK-X was designed based on EN/IEC
61558-2-16. Currently, IEC 61558-2-17 has been replaced by IEC
61558-2-16. When certification was received for EN/IEC 60204-1
(Machinery Safety), it was necessary to go through a control
transformer to the control circuits. However, a control transformer
is not always necessary for product that have been certified for
the safety standard for OVCIII or for product that use a
transformer that conforms to EN/IEC 61558-2-16.
• Safety Standards for a DC Input When DC is used, UL 60950-1, UL
62368-1, cUR (CSA 22.2 No. 60950-1), cUR (CSA C22.2 No. 62368-1),
EN/IEC 60950-1, EN/IEC 62368- 1, EN 50178 and EN/IEC 61558-2-16 are
applicable to safety standards. Safety standard compliance is
achievable by connecting a UL-certified fuse as specified below.
Select an external fuse that satisfies the following conditions:
S8VK-X03005-EIP, S8VK-X06012-EIP, S8VK-X06024-EIP (350 VDC or more,
6 A) S8VK-X09024@-EIP, S8VK-X12024@-EIP, S8VK-X24024@-EIP (350 VDC
or more, 8 A) S8VK-X48024@-EIP (350 VDC or more, 12 A)
• To comply with PELV output requirements for EN/IEC 60204-1,
ground the negative side of the output (-V) to a protective earth
(PE).
| Output | Rated output current | 20 A |
|---|
| Output voltage variable range | 21.6 to 28 V (With V.ADJ) |
|---|
| Rated output power | 480 W |
|---|
| Maximum peak current | 30 A |
|---|
| Ripple | 130 mV(p-p) max. at 20 MHz |
|---|
| Static input variation influence | 0.5% max. |
|---|
| Static load variation influence | 1.5% max. |
|---|
| Ambient temperature variation influence | 0.05%/℃ max. |
|---|
| Start up time | 1000 ms max. (at 115 VAC input)
1000 ms max. (at 230 VAC input) |
|---|
| Hold time | 25 ms typ. (at 115 VAC input)
25 ms typ. (at 230 VAC input) |
|---|
| Additional functions | Overload protection | Yes, automatic reset, intermittent operation type |
|---|
| Overvoltage protection | Yes, 130% or higher of rated output voltage, power shut off (shut
off the input voltage and turn on the input again) |
|---|
| Series operation | Yes (Up to 2 Power Supplies with external diode) |
|---|
| Parallel operation | Yes (Up to 2 Power Supplies) |
|---|
| Alarm indication | Yes (color: red) |
|---|
| Output indicator | Yes (color: green) |
|---|
| Output voltage indication | Yes |
|---|
| Output current indication | Yes |
|---|
| Peak-hold current indication | Yes |
|---|
| Total run time monitor | Indication: Yes |
|---|
