AB 1606-XLE480EP Power Supply 480W 24VDC 20A Single Phase Input
About 1606-XLE480EP :
The most outstanding features of this 1606-XLS power supply are the
high efficiency and the small size, which are achieved by a
synchronous rectification and further novel design details.
With short-term power capability of 150% and built-in large sized
output capacitors, these features help start motors, charge
capacitors and absorb reverse energy. A wide range input voltage
design and a negligible low input inrush current make installation
and usage simple. Diagnostics are easy due to the DC-ok relay, a
green DC-ok and a red overload LED.
Unique quick-connect spring-clamp terminals allow a safe and fast
installation. Many global approvals make this unit suitable for
nearly every situation
- Ultra-small size
- Extra-low inrush current
- Active power factor correction
- Wide range AC/DC input; auto select input
- Superior reserve power (can support 150% rated power for five
seconds)
- Superior efficiency and temperature rating
- DC-OK and overload LED
Typically, a load current is not constant. It varies over time. For
pulse load compatibility, following rules must be met:
a) The pulse power demand must be below 150% of the nominal power.
b) The duration of the pulse power must be shorter than the allowed
Power-Boost Time. (see output section)
c) The average (R.M.S.) output current must be below the specified
continuous output current. If the R.M.S. current is higher, the
unit will respond with a thermal shut-down after a while. Use the
max. duty cycle curve (Fig. 27-2) to check if the average output
current is below the nominal current.
d) For altitudes higher than 2000m reduce the pulse loading
(30W/1000m) or the ambient temperature
Bulletin 1606-:
Quick mounting and connecting, innovative DIN-Rail mount, smallest
in class
UL Listed NEC Class 2; Class 1, Div. 2; Semi F47; ODVA Approved
Low inrush current limiting
PFC Active or Passive
Wide range input; auto select input
Superior overload design (continuous current, no hiccup)
NEC Class 2 'Limited Power' options
Selectable operating mode (single/parallel)
Superior efficiency and temperature rating
Instructions:
a) Use appropriate copper cables that are designed for an operating
temperature of: 60°C for ambient up to 45°C and 75°C for ambient up
to 60°C minimum.
b) Follow national installation codes and installation regulations!
c) Ensure that all strands of a stranded wire enter the terminal
connection!
d) Up to two stranded wires with the same cross section are
permitted in one connection point (except PE wire).
e) Do not use the unit without PE connection.
1606-XLE120E & 1606-XLE120EC 24V, 5A; Single Phase Input
Instructions for two phase operation:
a) A phase to phase connection is allowed as long as the supplying
voltage is below 240V(+10%).
b) Use a fuse or a circuit breaker to protect the N input. The N
input is internally not protected and is in this case connected to
a hot wire
Adisadvantages:
a. The faulty power supply can not be recognized. The green LED
will still be on since it is reverse-powered from the other power
supply.
b. It does not cover failures such as an internal short circuit in
the secondary side of the power supply. In such a - virtually
nearly impossible - case, the defective unit becomes a load for the
other power supplies and the output voltage can not be maintained
any more.
Another module:
SLC 500 Digital I/O Modules Input Catalog Numbers1746-IA4, 1746-IA8, 1746-IA16, 1746-IB8, 1746-IB16, 1746-IC16,
1746-IG16, 1746-IH16, 1746-IM4, 1746-IM8, 1746-IM16, 1746-IN16,
1746-ITB16, 1746-ITV16, 1746-IV8, 1746-IV16
Output Catalog Numbers1746-OA8, 1746-OA16, 1746-OAP12, 1746-OB8, 1746-OB6EI, 1746-OB16,
1746-OB16E, 1746-OBP8, 1746-OBP16, 1746-OG16, 1746-OV8, 1746-OV16,
1746-OVP16, 1746-OW4, 1746-OW8, 1746-OW16, 1746-OX8
Combination Input/Output Catalog Numbers1746-IO4, 1746-IO8, 1746-IO12, 1746-IO12DC
