MITSUBISHI MELSERVO INDUSTRIAL AC SERVO DRIVE 400W MR-J3-40B New
Amplifier in stock
MITSUBISHI MR-J3-40B 400W AC SERVO DRIVER
(Specifications taken from manual)
Input Voltage/frequency: 1-phase 100-120VAC, 50/60Hz
Permissible voltage fluctuation: 172-253VAC
Output: 200V
Control System: Sine-wave PWM control/current control system
Position control mode
Maximum input pulse frequency: 1000kpps (when using differential
receiver), 200kpps (when using open collector)
Speed control mode
Speed control range: analog speed command 1:2000, internal speed
command 1:5000
Torque control mode
Torque command input: 0-±8V DC maximum torque (input impedance
10-12kOhm)
encoder resolution: 262144 pulses per rev.
Position and Speed Control: Analog inputs and pulse train interface
Output Power: 400W
Mass: 1.0kg
(If you need further data, please search Google or similar, since
it's no longer allowed to put links to manuals here.)
This Servo Driver - MR-J3-40B - is to be used with HF-MP43*,
HF-KP43* Servo Motors.
The following functions of the MR-J3-40B (GA) model is deleted:
Master-slave operation
Encoder Z-phase pulse output
The following functions of the MR-J3-40B (GA) model is changed:
CN1A/CN1B is always lit. (Note 2)
(Same while the cable and the cap are used.)
Description of Mitsubishi AC Servo Amplifier
- High-speed controllers for ultra-short positioning times; average
speed frequency response 2100Hz
- High-resolution encoders for maximum speed constancy (18 bits
262,144 P/rev)
- Advanced vibration suppression for outstanding adaptation to
machine requirements
- Auto tuning for extremely fast setup and installation
- Optimum cost/benefit ratio
- Absolute position encoder included as standard equipment
- Minimum wiring overheads thanks to Plug & Play configuration and
automatic motor identification
- Supports global standards
