OMRON R88G-HPG14A45050B 50 WATT 3000-R/MIN SERVOMOTORS BACKLASH 3
ARCMINUTES MAX
Product information OMRON R88G-HPG14A45050B :
- R88GHPG14A45050B
- DECELERATOR
- 60 X 60
- 1/45
- 50 WATT
- 3000-R/MIN SERVOMOTORS
- BACKLASH: 3 ARCMINUTES MAX
- STRAIGHT SHAFT
• Standard and high inertia servo motor models
• Peak torque 300% of rated torque during 3 seconds or more
depending on model
• High resolution serial encoder provided by 20 bits encoder
• IP67 protection in all models
• Ultra-light and compact size motor
• Low speed ripple and low torque ripple due to low torque cogging
• Various shaft, brake and seal options
In the features:
• Industry Top-class Tracking Performance. Speed Response Frequency
of 2 kHz.
• Best Positioning Accuracy*. Featuring a 20-bit high-resolution
incremental encoder.
* 8 times the resolution of previous OMRON models
• High-precision Positioning. Fully Closed Loop Control Is a
Standard Feature.
• Conforms to the Latest International Standards. Safety and
Productivity.
• Globalization. Lineup of 400 VAC Servomotors.
Note: 1. The values inside parentheses ( ) are for 100-V
Servomotors.
Note: 2. The Decelerator inertia is the Servomotor shaft conversion
value.
Note: 3. The protective structure for Servomotors with Decelerators
satisfies IP44.
Note: 4. The allowable radial load is the value at the T/2
position.
Note: 5. The standard models have a straight shaft. Models with a
key and tap are indicated by adding "J" to the end of
the model number (the suffix in the box).
Decelerators for 3,000-r/min Cylindrical Servomotors
Straight shaft
Same series of R88 - :
R88D-GN04H-ML2 : G-Series servo drive, 1~ 200 VAC, MECHATROLINK II integrated, 400 W
R88M-G40030H-BS2 : G-Series/SmartStep 2 AC servo motor (cylinder type), 400 W, 200
VAC, 3000 rpm, 1.3 Nm, with brake
R88M-G40030H-BS2-D: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, incremental,
Brake, with circular connector
R88M-G40030T-BS2: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, absolute, Brake
R88M-G40030T-BS2-D: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, absolute, Brake,
with circular connector
R88M-GP40030T-BS2-D: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, absolute, Brake,
with circular connector
Details:
Similar Model Products:
| Specifications | Model |
|---|
| Power Model Supply Voltage | Applicable Servomotor Capacity |
|---|
Single-phase
100 VAC | 50 W | R88D-KTA5L |
|---|
| 100 W | R88D-KT01L |
|---|
| 200 W | R88D-KT02L |
|---|
| 400 W | R88D-KT04L |
|---|
Single-phase/three-phase
200 VAC | 100 W | R88D-KT01H |
|---|
| 200 W | R88D-KT02H |
|---|
| 400 W | R88D-KT04H |
|---|
| 750 W | R88D-KT08H |
|---|
| 1 kW | R88D-KT10H |
|---|
| 1.5 kW | R88D-KT15H |
|---|
Three-phase
200 VAC | 2 kW | R88D-KT20H |
|---|
| 3 kW | R88D-KT30H |
|---|
| 5 kW | R88D-KT50H |
|---|
| 7.5 kW | R88D-KT75H |
|---|
| 15 kW | R88D-KT150H |
|---|
Three-phase
400 VAC | 600 W | R88D-KT06F |
|---|
| 1 kW | R88D-KT10F |
|---|
| 1.5 kW | R88D-KT15F |
|---|
| 2 kW | R88D-KT20F |
|---|
| 3 kW | R88D-KT30F |
|---|
| 5 kW | R88D-KT50F |
|---|
| 7.5 kW | R88D-KT75F |
|---|
| 15 kW | R88D-KT150F |
|---|
| Motor capacity | Gear Ratio | Model (Straight shaft) |
|---|
| 50 W | 1/5 | R88G-HPG11B05100B |
| 1/9 | R88G-HPG11B09050B |
| 1/21 | R88G-HPG14A21100B |
| 1/33 | R88G-HPG14A33050B |
| 1/45 | R88G-HPG14A45050B |
| 100 W | 1/5 | R88G-HPG11B05100B |
| 1/11 | R88G-HPG14A11100B |
| 1/21 | R88G-HPG14A21100B |
| 1/33 | R88G-HPG20A33100B |
| 1/45 | R88G-HPG20A45100B |
| 200 W | 1/5 | R88G-HPG14A05200B |
| 1/11 | R88G-HPG14A11200B |
| 1/21 | R88G-HPG20A21200B |
| 1/33 | R88G-HPG20A31400B |
| 1/45 | R88G-HPG20A45200B |
| 400 W | 1/5 | R88G-HPG14A05400B |
| 1/11 | R88G-HPG20A11400B |
| 1/21 | R88G-HPG20A21400B |
| 1/33 | R88G-HPG32A33400B |
| 1/45 | R88G-HPG32A45400B |
750 W
(200 V) | 1/5 | R88G-HPG20A05750B |
| 1/11 | R88G-HPG20A11750B |
| 1/21 | R88G-HPG32A21750B |
| 1/33 | R88G-HPG32A33750B |
| 1/45 | R88G-HPG32A45750B |
750 W
(400 V) | 1/5 | R88G-HPG32A052K0B |
| 1/11 | R88G-HPG32A112K0B |
| 1/21 | R88G-HPG32A211K5B |
| 1/33 | R88G-HPG32A33600SB |
| 1/45 | R88G-HPG50A451K5B |
| 1 kW | 1/5 | R88G-HPG32A052K0B |
| 1/11 | R88G-HPG32A112K0B |
| 1/21 | R88G-HPG32A211K5B |
| 1/33 | R88G-HPG50A314K0B |
| 1/45 | R88G-HPG50A451K5B |
| 1.5 kW | 1/5 | R88G-HPG32A052K0B |
| 1/11 | R88G-HPG32A112K0B |
| 1/21 | R88G-HPG32A211K5B |
| 1/33 | R88G-HPG50A314K0B |
| 1/45 | R88G-HPG50A451K5B |
| 2 kW | 1/5 | R88G-HPG32A052K0B |
| 1/11 | R88G-HPG32A112K0B |
| 1/21 | R88G-HPG50A212K0B |
| 1/33 | R88G-HPG50A314K0B |
| 3 kW | 1/5 | R88G-HPG32A053K0B |
| 1/11 | R88G-HPG50A113K0B |
| 1/21 | R88G-HPG50A213K0B |
| 4 kW | 1/5 | R88G-HPG32A054K0B |
| 1/11 | R88G-HPG50A115K0B |
| 5 kW | 1/5 | R88G-HPG50A055K0B |
| 1/11 | R88G-HPG50A115K0B |
