Omron R7D-AP04L Servo AC 100VAC Supply 2.6A 100V Load 400 W SERVO
DRIVE
Product information OMRON R7D-AP04L :
AC Servo Drive - OMRON (R7D) - Single phase input - Supply voltage
100Vac - (Continous output current) 1A - (Maximum motor capacity
50W) 0.050kW
• High-speed Response The G-series AC Servomotors and Servo Drives
have achieved high-speed response capabilities, with a highresponse
frequency of 1 kHz.
• Suppressing Vibration of Low-rigidity Mechanisms during
Acceleration/Deceleration The damping control function suppresses
vibration of low-rigidity mechanisms or devices whose ends tend to
vibrate.
Two damping filters are provided to enable switching the vibration
frequency automatically according to the direction of rotation and
also via an external signal. In addition, the settings can be made
easily merely by setting the vibration frequency and filter values,
and you are assured of stable operation even if the settings are
inappropriate.
• High-speed Positioning via Resonance Suppression Control The
realtime autotuning function automatically estimates the load
inertia of the machine in realtime and sets the optimal gain. The
adaptive filter automatically suppresses vibration caused by
resonance. Also, two independent notch filters make it possible to
reduce vibration of a mechanism with multiple resonance
frequencies.
- SERVO DRIVE
- SMARTSTEP SERIES
- 100-115 VAC INPUT
- 50/60 HZ
- SINGLE PHASE
- 11 AMP
- 0-240 VAC OUTPUT
- 2.6 AMP
Same series of R88 - :
R88D-GN04H-ML2 : G-Series servo drive, 1~ 200 VAC, MECHATROLINK II integrated, 400 W
R88M-G40030H-BS2 : G-Series/SmartStep 2 AC servo motor (cylinder type), 400 W, 200
VAC, 3000 rpm, 1.3 Nm, with brake
R88M-G40030H-BS2-D: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, incremental,
Brake, with circular connector
R88M-G40030T-BS2: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, absolute, Brake
R88M-G40030T-BS2-D: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, absolute, Brake,
with circular connector
R88M-GP40030T-BS2-D: AC servo motor, 400 W, 200 VAC, 3000 rpm, 1.3 Nm, absolute, Brake,
with circular connector
Details:
Similar Model Products:
| Specifications | Model |
|---|
| Single-phase 100 VAC | 50 W | R7D-BPA5L |
| 100 W | R7D-BP01L |
| 200 W | R7D-BP02L |
| Single-phase/three-phase 200 VAC | 50 W | R7D-BP01H |
| 100 W |
| 400 W | R7D-BP04H |
| Single-phase 200 VAC | 200 W | R7D-BP02HH |
| Three-phase 200 VAC | 200 W | R7D-BP02H |
| Item | Specifications |
|---|
Ambient operating temperature
Ambient operating humidity | 0 to 55 °C, 90% max. (with no condensation) |
|---|
Ambient storage temperature
Ambient storage humidity | -20 to 65 °C, 90% max. (with no condensation) |
|---|
| Storage and operating atmosphere | No corrosive gasses, no dust, no iron dust, no exposure to moisture
or
cutting oil |
|---|
| Vibration resistance | 10 to 60 Hz; acceleration: 5.9 m/s2 (0.6 G) max. |
|---|
| Impact resistance | Acceleration of 19.6 m/s2 max. 3 times each in X, Y, and Z directions. |
|---|
| Insulation resistance | Between power supply/power line terminals and frame ground: 0.5 MΩ.
min. (at 500 VDC) |
|---|
| Dielectric strength | Between power supply/power line terminals and frame ground: 1,500
VAC for 1 min at 50/60 Hz
Between each control signal and frame ground: 500 VAC for 1 min |
|---|
| Altitude | 1,000 m above sea level max. (860 hp min.) |
|---|
| Degree of protection | Built into panel (IP10). |
|---|
International
standards | EC
Directives | EMC Directive | EN 55011 class A group 1
EN 61000-6-2 |
|---|
Low Voltage
Directive | EN 50178 |
|---|
| UL standards | UL 508C |
|---|
| cUL standards | cUL C22.2 No.14 |
|---|
Korean Radio Regulations
(KC) | Certified |
|---|
| Specifications | Model |
|---|
| Power Model Supply Voltage | Applicable Servomotor Capacity |
|---|
Single-phase
100 VAC | 50 W | R88D-KTA5L |
|---|
| 100 W | R88D-KT01L |
|---|
| 200 W | R88D-KT02L |
|---|
| 400 W | R88D-KT04L |
|---|
Single-phase/three-phase
200 VAC | 100 W | R88D-KT01H |
|---|
| 200 W | R88D-KT02H |
|---|
| 400 W | R88D-KT04H |
|---|
| 750 W | R88D-KT08H |
|---|
| 1 kW | R88D-KT10H |
|---|
| 1.5 kW | R88D-KT15H |
|---|
Three-phase
200 VAC | 2 kW | R88D-KT20H |
|---|
| 3 kW | R88D-KT30H |
|---|
| 5 kW | R88D-KT50H |
|---|
| 7.5 kW | R88D-KT75H |
|---|
| 15 kW | R88D-KT150H |
|---|
Three-phase
400 VAC | 600 W | R88D-KT06F |
|---|
| 1 kW | R88D-KT10F |
|---|
| 1.5 kW | R88D-KT15F |
|---|
| 2 kW | R88D-KT20F |
|---|
| 3 kW | R88D-KT30F |
|---|
| 5 kW | R88D-KT50F |
|---|
| 7.5 kW | R88D-KT75F |
|---|
| 15 kW | R88D-KT150F |
|---|
Note: 1. The above items reflect individual evaluation testing. The
results may differ under compound conditions.
Note: 2. Always disconnect all connections to the Servo Drive
before you perform insulation resistance tests on it. If you
perform an insulation resistance test while the Servo Drive is
connected, the Servo Drive may be damaged.
Never perform dielectric strength tests on the Servo Drive. Failure
to follow this precaution may result in
damaging internal elements.
Note: 3. Depending on the operating conditions, some Servo Drive
parts will require maintenance.
