Mitsubishi 3 phase AC Servo Driver MR-J3-700B 7KW Motor Amplifier
in control system NEW
I.Quick Details:
| Brand/Manufacturer | Mitsubishi Electric |
| Model | MR-J3-700B |
| Product Type | AC Servo Drive |
| Product Range | MELSERVO MR-J3 Series |
| Power Rating | 7kW |
| Input | 28.9A 3PH 200-230vAC 50/60Hz |
| Output | 37A 170v 0-360Hz |
II.Product Information:
The Mitsubishi MR-J3-700B (MRJ3700B) is a 7kW, 200V MELSERVO MR-J3
servo amplifier SSC NETWORK. The voltage operates on 3-phases,
while the voltage range is 200 to 230VAC, and a frequency of
50/60Hz. The authorized voltage range is nevertheless 170 to 253VAC
and the sanctioned frequency range is -5% to +5%. The MR-J3-700B
servo amplifier also utilizes the SSCNET system that has a speed of
50Mbps.
The HC-SP702 servo motor is the only servo motor that may connect
with the MR-J3-700B servo amplifier. The ways in which this servo
motor may link with the servo amplifier is delineated below.
The MR-J3-700B servo amplifier has multiple ports and connectors.
The CN5 port of this servo amplifier connects using a MR-J3USBCBL3M
cable to a personal computer that employs a MR Configurator. The
personal computer may also attach to a Q series configuration. Then
the CN3 port can attach to an I/O signal. The MR-J3-700B servo
amplifier has a CN1A port may attach to a motion control module
from the Q series configuration with a SSCNET III. The CN1A port
may also, using the SSCNET III, connect to the CN1B port of a
similar servo amplifier and vice-versa. Below these ports is also a
CN2 port that attaches to the encoder if the HC-SP702 servo motor.
Concerning the connectors of the MR-J3-700B servo amplifier, the
CNP3 (U, V, W) connector may link to the servo motor as its power
supply. The other two connectors, the CNP2 and CNP3 connector are
then used as both power supplies, the main and control circuit.
III.Technical Specifications
Part Number: MR-J3-700B (MRJ3700B)
Module Type: Servo Amplifier
Voltage/Frequency: 200 to 230VAC, 3-phase 50/60Hz
Output Wattage: 5kW
Weight: 13.67lbs (6.2kg)
IV.Transportation and installation
| Environment | Condition |
| Servo amplifier | Servo motor |
| Ambient temperature | In operation | °C | 0 to 55 (non-freezing) | 0 to 40 (non-freezing) |
| °F | 32 to 131 (non-freezing) | 32 to 104 (non-freezing) |
