Communications processor CP 443-1; 2x 10/100 Mbit/s (IE switch); RJ45 ports; ISO; TCP; UDP; PROFINET IO controller; S7 communication; Open communication (SEND/ RECEIVE); S7 routing; IP configuration via DHCP/ Block; IP Access control list; time-of-day synchronization; extended web diagnostics; Fast Startup; Support for PROFIenergy;

Article Number:

6GK7443-1EX30-0XE0

product type designation:

Communications processor CP 443-1; 2x 10/100 Mbit/s (IE switch); RJ45 ports; ISO; TCP; UDP; PROFINET IO controller; S7 communication; Open communication (SEND/ RECEIVE); S7 routing; IP configuration via DHCP/ Block; IP Access control list; time-of-day synchronization; extended web diagnostics; Fast Startup; Support for PROFIenergy;

transfer rate

● at the 1st interface: 10 ... 100 Mbit/s

interfaces number of interfaces / according to Industrial Ethernet :2

number of electrical connections

● at the 1st interface / according to Industrial Ethernet :2

type of electrical connection

● at the 1st interface / according to Industrial Ethernet: RJ45 port

design of the removable storage

● C-PLUG: No

type of voltage / of the supply voltage: DC

supply voltage / 1 / from backplane bus: 5 V

relative symmetrical tolerance / at DC

● at 5 V: 5 %

consumed current

● from backplane bus / at DC / at 5 V / typical: 1.4 A

power loss [W] :7.25 W

ambient temperature

● during operation 0 ... 60 °C

● during storage -40 ... +70 °C

● during transport -40 ... +70 °C

relative humidity

● at 25 °C / without condensation / during operation / maximum: 95 %

protection class IP: IP20

Product Lifecycle (PLM) PM300:Active Product

Product family CP 443-1

Region Specific PriceGroup / Headquarter Price Group 5P2 / 5P2

Export Control Regulations AL : N / ECCN : 9N9999

Net Weight (kg) 0,833 Kg

Packaging Dimension 35,00 x 129,00 x 142,00

Commodity Code: 85176200

LKZ_FDB/ CatalogID: IK

Product Group: 2414

Group Code: R322

Country of origin: Germany

Compliance with the substance restrictions according to RoHS directive Since: 11.05.2012

Product class: A: Standard product which is a stock item could be returned within the returns guidelines/period.

WEEE (2012/19/EU) Take-Back Obligation: Yes

REACH Art. 33 Duty to inform according to the current list of candidates :

Lead CAS-No. 7439-92-1 > 0, 1 % (w / w)
Tris(4-nonylphenyl, branc... > 0, 1 % (w / w)

SCIP number 82bdb3b0-4fc6-482a-a1e6-fba13d7ad2f4
